MODEL NUMBER :
ZONKE PRO POLE Ø114

BODY : Galvanised Steel.
MOUNTING : Plinth Mounted or Buried.
FINISH : Raw or Powder coated.
ACCESSORIES : Bolt cage.
FEATURES : Pole designs are done in accordance with SABS 0225 Specification.
A Certificate of Conformance on the design (signed by a registered Professional Engineer) is available for all poles manufactured.
All products manufactured are Hot Dip Galvanised by a SABS approved Galvaniser in accordance to SANS 121 / SABS 1461 Specification. Only Galvanisers which are Members of the HDGASA (Hot Dip Galvanising Association of SA) are used.
All poles are manufactured from Grade S355 steel manufactured in accordance to SANS 657/1&3 Specification.
All poles are manufactured to the required specification of the specific Council.
All products are galvanised prior to Powder Coating.

NOTE : All Galvanised steel poles are manufactured to client requirements and are
designed to accommodate luminaire selection and environmental conditions.

To be approved by Civil Engineer
- Size of concrete plinth
- Reinforcement for concrete plinth
- Bolt cage size subject to application
- Buried depth
