EUROPA

This is a bollard that is suitable for modern architecture. Ideal for creating visual guidance with exceptional visual comfort. Suitable for pedestrian areas, building surrounds, shopping centers, squares and parks. The luminaire has no light above the horizontal.


Ideal solution for landscape & pedestrian areas.

Asymmetrical light distribution.

9W | 3000K - 4000K | 1356 lm - 1435 lm

Plinth mounted or buried.

IP54.

Recommended mounting height 1m.

SPECIFICATIONS

MODEL NUMBER :
EUROPA

HOUSING : LM 6 die cast aluminium and extruded aluminium.
LIGHT SOURCE : The fitting is designed to operate a LED up to 9W.
DIFFUSER : Tempered glass clear.
LENSES : Modular optical lenses. Material PMMA.
Various lens options available for different applications, allowing for custom solutions.
FINISH : Powder coated.
MOUNTING : Plinth mounted or buried.
ACCESSORIES : Must be specified when ordering.
Available accessories - Access door, MCB and bolt cage.
CONTROL GEAR : Electronic or magnetic control gear. The electronic supply is suitable for operation with 220 – 240 volts - 50 hertz single phase.
FASTENERS : All external screws are stainless steel.
GASKET : Silicone sponge gasket.
INGRESS PROTECTION : IP54.
MECHANICS : Operating Temperature (Ta) ≤ 35° C.
Weight : 8 Kg.
Windage : Max . projected areas for mounting 0.122m².
FEATURES : Surge arrester to protect LED supply.

COLOURS
LIGHT SOURCE

LED Osram Square Giant

LED CURRENT (mA)NOMINAL WATTAGE
(W)
COLOUR TEMP (K)NOMINAL FLUX (lm)
700mA9W4000K1435 lm
3000K1356 lm

The environmental conditions of the installation will impact the efficiency of the LED’s.
Due to the continual advancement in LED technology the type of LED is subject to change.



LIGHT DISTRIBUTION

APPLICATION AREAS
  • Indoor or outdoor application.
  • Asymmetrical distribution.
  • Parks and gardens.
  • Pedestrian walkways.
  • Building entrances.
  • Parking areas.

TECHNICAL
INSTALLATION INSTRUCTIONS
Installation Instructions available on request
CERTIFICATIONS

bollardsIP54  LED SABS approved
